Tipo S-950 (1956)

Tipo S-950 (1956)

Type - tipo "S"
Body - 2 Seat Spider
Dry Weight - kg 430

Chasis Measures
Length - mm 2100
Track - Front - mm 1145
Track - Rear - mm 1130

Engine - tipo "950"
Number of Cylinders - 4
Bore - mm 70
Stroke - mm 62
displacment per Cylinder - cm3 238.60
Total Displacmnt - cm3 954.43
Compression - 9.9:1
Max Power - 78 hp @ 7200 RPM
Valve Gear - Twin cam, chain driven gears
Carburatoin - 2 X Weber 35 DCOA3
Ignition - Single spark plug, distributor
fuel Pump - electric pump
Lubrication - electric pump

Clutch
single disk

Transmission
4 forward + reverse

Chassis
Tubolar with longentudal support tubes

Front Suspention
Independent, Triangulat A-Arms,
telescopic shocks, Helical springs, anti roll-bar

Rear Suspension
Longentudunal semi independent leaf-spring,
telescopic shocks

Brakes
hydrolic drum brakes 4 wheels

Rims
Borrani or Amadori type, wired or disk 3.5X14

Tyres
5.20X14

Fuel Tank
50 Liters

Max Speed
190 km/h

Date

01 March 2020
