Tipo G 4500 (1951)

Tipo G 4500 (1951)

Type - tipo "G"
Body - Single Seater, later Coupe (Zagato)
Dry Weight - kg 760

Chasis Measures
Length - mm 2450
Track - Front - mm 1280
Track - Rear - mm 1260

Engine - tipo "G"
Number of Cylinders - V12 60o
Bore - mm 78
Stroke - mm 78
displacment per Cylinder - cm3 372.71
Total Displacmnt - cm3 4472.50
Compression - 12:1
Max Power - 330 hp @ 6200 RPM
Valve Gear - Single cam per bank, chain driven gears
Carburatoin - 3 X Weber DCF
Ignition - Single spark plug, Magneto
fuel Pump - electric pump
Lubrication - electric pump, dry sump

Clutch
Multi disk disk

Transmission
4 forward + reverse

Chassis
Tubolar with longentudal support tubes

Front Suspention
Independent, Triangulat A-Arms,
telescopic shocks, Helical springs, anti roll-bar

Rear Suspension
De Dion type, tursion bars,
Hydrolic dampers

Brakes
hydrolic drum brakes 4 wheels

Rims
Borrani type, spoked 3.50X17 (front) 5.00x17 (rear)

Tyres
5.0-17 (front) 7.00-17 (rear)

Fuel Tank
N/A

Max Speed
260 km/h

Date

01 March 2020
